钕铁硼磁铁性能一览表
2024-07-08 16:40 通立钕铁硼磁铁厂家
| Number 牌号 | Remanence 剩磁 | Magnetic induction obstinacy 磁感应强度矫顽力 | Magnetization 磁极化强度矫顽力 | Maximum magnetic energy product 最大磁能积 | Operating temperature 工作温度 |
| Grade | Br：KGs（mT） | Hcb：Koe（KA/m） | Hcj:Koe(KA/m) | （BH)max:MGOe(Kj/m3) | （TW）℃ |
| N35 | 11.8-12.2(1180-1220) | ≧10.8(860) | ≧12.0(955) | 33-36(262-286) | ≦80 |
| N38 | 12.2-12.6(1220-1260) | ≧10.8(860) | ≧12.0(955) | 36-39(286-310) | ≦80 |
| N40 | 12.6-12.9(1260-1290) | ≧11.0(876) | ≧12.0(955) | 38-40(302-318) | ≦80 |
| N42 | 12.9-13.3(1290-1330) | ≧11.0(876) | ≧12.0(955) | 40-43(318-343) | ≦80 |
| N45 | 13.3-13.7(1330-1370) | ≧11.0(876) | ≧12.0(955) | 43-46(343-366) | ≦80 |
| N48 | 13.7-14.0(1370-1400) | ≧10.8(860) | ≧12.0(955) | 46-49(366-390) | ≦80 |
| N50 | 14.0-14.4(1400-1440) | ≧10.5(836) | ≧12.0(955) | 48-50(382-398) | ≦80 |
| N52 | 14.2-14.5(1420-1450) | ≧10.5(836) | ≧12.0(955) | 50-52(398-413) | ≦80 |
| N54 | 14.5-14.9(1450-1490) | ≧10.5(836) | ≧11.0(876) | 51-55(406-438) | ≦80 |
| N56 | 14.8-15.2(1480-1520) | ≧10.5(836) | ≧11.0(876) | 52-57(414-454) | ≦80 |
| N35M | 11.8-12.2(1180-1220) | ≧10.8(860) | ≧14.0(1114) | 33-36(262-286) | ≦100 |
| N38M | 12.2-12.6(1220-1260) | ≧11.0(876) | ≧14.0(1114) | 36-39(286-310) | ≦100 |
| N40M | 12.6-12.9(1260-1290) | ≧11.4(910) | ≧14.0(1114) | 38-40(302-318) | ≦100 |
| N42M | 12.9-13.3(1290-1330) | ≧11.8(938) | ≧14.0(1114) | 40-43(318-343) | ≦100 |
| N45M | 13.3-13.7(1330-1370) | ≧11.8(938) | ≧14.0(1114) | 43-46(343-366) | ≦100 |
| N48M | 13.7-14.0(1370-1400) | ≧12.8(1019) | ≧14.0(1114) | 46-49(366-390) | ≦100 |
| N50M | 14.0-14.4(1400-1440) | ≧13.1(1043) | ≧14.0(1114) | 48-50(382-398) | ≦100 |
| N52M | 14.2-14.8(1420-1440) | ≧13.3(1059) | ≧14.0(1114) | 49-59(390-422) | ≦100 |
| N35H | 11.8-12.2(1180-1220) | ≧11.0(876) | ≧17.0(1353) | 33-36(262-286) | ≦120 |
| N38H | 12.2-12.6(1220-1260) | ≧11.0(876) | ≧17.0(1353) | 36-39(286-310) | ≦120 |
| N40H | 12.6-12.9(1260-1290) | ≧11.5(915) | ≧17.0(1353) | 38-40(302-318) | ≦120 |
| N42H | 12.9-13.3(1290-1330) | ≧11.8(938) | ≧17.0(1353) | 40-43(318-343) | ≦120 |
| N45H | 13.3-13.7(1330-1370) | ≧11.8(938) | ≧17.0(1353) | 43-46(343-366) | ≦120 |
| N48H | 13.7-14.0(1370-1400) | ≧12.2(938) | ≧17.0(1353) | 46-49(366-390) | ≦120 |
| N50H | 14.0-14.4(1400-1440) | ≧12.2(938) | ≧17.0(1353) | 48-50(382-398) | ≦120 |
| N52H | 14.5-15.3(1450-1530) | ≧13.0(1035) | ≧16.0(1274) | 52-55(414-438) | ≦120 |
| N35SH | 11.8-12.2(1180-1220) | ≧11.0(876) | ≧20.0(1593) | 33-36(262-286) | ≦150 |
| N38SH | 12.2-12.6(1220-1260) | ≧11.0(876) | ≧20.0(1593) | 36-39(286-310) | ≦150 |
| N40SH | 12.6-12.9(1260-1290) | ≧11.5(915) | ≧20.0(1593) | 38-40(302-318) | ≦150 |
| N42SH | 12.9-13.3(1290-1330) | ≧11.8(938) | ≧20.0(1593) | 40-43(318-343) | ≦150 |
| N45SH | 13.3-13.7(1330-1370) | ≧12.2(970) | ≧20.0(1593) | 43-46(343-366) | ≦150 |
| N48SH | 13.7-14.3(1370-1430) | ≧12.7(1011) | ≧20.0(1593) | 45-49(358-390) | ≦150 |
| N30UH | 10.8-11.4(1080-1140) | ≧10.1(804) | ≧25.0(1990) | 28-31(223-246) | ≦180 |
| N33UH | 11.3-11.7(1130-1170) | ≧10.3(820) | ≧25.0(1990) | 30-33(239-262) | ≦180 |
| N35UH | 11.8-12.2(1180-1220) | ≧11.2(892) | ≧25.0(1990) | 33-36(262-286) | ≦180 |
| N38UH | 12.2-12.6(1220-1260) | ≧11.5(915) | ≧25.0(1990) | 36-39(286-310) | ≦180 |
| N40UH | 12.6-12.9(1260-1290) | ≧11.8(938) | ≧25.0(1990) | 38-40(302-318) | ≦180 |
| N42UH | 12.9-13.3(1290-1330) | ≧12.2(970) | ≧25.0(1990) | 40-43(318-343) | ≦180 |
| N45UH | 13.3-13.7(1330-1370) | ≧10.1(804) | ≧25.0(1990) | 43-46(343-366) | ≦180 |
| N30EH | 10.8-11.4(1080-1140) | ≧10.3(820) | ≧30.0(2388) | 28-31(223-246) | ≦200 |
| N33EH | 11.3-11.7(1130-1170) | ≧11.0(876) | ≧30.0(2388) | 30-33(239-262) | ≦200 |
| N35EH | 11.8-12.2(1180-1220) | ≧11.2(892) | ≧30.0(2388) | 33-36(262-286) | ≦200 |
| N38EH | 12.2-12.6(1220-1260) | ≧11.6(939) | ≧30.0(2388) | 36-39(286-310) | ≦200 |
| N40EH | 12.6-12.9(1260-1290) | ≧10.8(900) | ≧30.0(2388) | 38-40(302-318) | ≦200 |
| N30AH | 10.8-11.4(1080-1140) | ≧10.1(804) | ≧35.0(2785) | 28-31(223-246) | ≦220 |
| N33AH | 11.3-11.7(1130-1170) | ≧10.3(820) | ≧35.0(2785) | 30-33(239-262) | ≦220 |
| N35AH | 11.7-12.1(1170-1210) | ≧10.9(876) | ≧35.0(2785) | 33-35(263-279) | ≦220 |
